Reel Dimensions and Volumes

There are various standard sizes of reels which are represented below :

DIN46397

Flange Dia.	Drum Diam.	Bore O.D.	Bore I.D.	Drive Pin	Drive  Pin RAD	Width Outside	Traverse	Vol.
[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[dm3]
		(*)		bore/pin
100	56	-	50	-	-	80	60	0.32
125	71		63			95	75	0.62
160	90		80			118	95	1.31
200	112		100	-	-	150	118	2.54
	125							2.26
	140							1.89
224	125		100			170	140	3.80
	140							3.36
	160							2.70
250	140	160	127	-	-	190	160	5.39
	160							4.64
	180							3.78
315	180	160	127	16	100	236	200	10.5
	200							9.30
	224							7.70
355	200	160	127			212	180	12.2
	200					265	224	15.1
	224							13.3
	250							11.2
400	224	160	127	28	100	236	200	17.3
	224					300	250	21.6
	250							19.1
	280							16.0
450	250	160	127			265	224	24.6
	250					335	280	30.8
	280							27.3
	315							22.7
500	280	160	127			300	250	33.7
	280					375	315	42.5
	315							37.5
	355							30.7
560	315	160	127			335	280	47.1
	315					425	355	59.8
	355							52.3
	400							42.8
630	355	160	127			375	315	67.0
	355					475	400	86.2
	400							74.4
	450							61.1
710	400	300	250	40	170	425	355	95.9
	400					530	450	121.6
	450							106.6
	500							89.8
800	450	300	250			475	400	137
	450					600	500	172
	500							153
	560							128
1000	560	200	250	50	250	750	630	340
	630							298
	710							245
1250	710	300	250			950	800	665
	800							580
	900							473
(*) standard value

DIN46397

Flange Dia.	Drum Diam.	Bore O.D.	Bore I.D.	Drive Pin	Drive  Pin RAD	Width Outside	Traverse	Vol.
[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[dm3]
		(*)		bore/pin
100	40	50	28	8 - 16	40	80	63	0.42
125	50					95	80	0.83
160	63					118	100	1.7
200	80*	71	36		71	150*	125*	3.3
	100	(63*)				125	100	2.35
250	100*					190*	160*	6.6
	125					150	125	4.6
315	125*					236*	200*	13.1
	160					190	160	9.2
355	140*	112	56	16 -28	112	265*	224*	18.7
	180	(80*)				215	180	13.2
400	160*					300*	250*	26.3
	200					236	200	18.8
450	180*					335*	280*	37.4
	224					265	224	26.8
500	200*				140	375*	315*	51.9
	250					300	250	36.8
560	224*					425*	355*	73.4
	280					335	280	51.7
630	250*	160				475*	400*	105.1
	315	(100*)				375	315	72.5
710	355	160	80	28-40	160	530	450	133.6
800	400	(125*)				600	500	188.5
900	450					670	560	267.2
1000	500					750	630	371.1
1120	560	160				850	710	524.6
1250	630					950	800	732.4
1400	710			40-63	300	1060	900	1029.1
1600	800					1180	1000	1508.0
1800	1000	200	100			1320	1120	1970.4
2000	1120					1500	1250	2695.5
2240	1250	250	125			1700	1400	3799.1
2500	1500					1900	1600	5026.5
2800	1800	280	140			2120	1800	6503.1
